OceanFlex Tinned Marine Battery Cable Black 35.0 sq.mm (~2 AWG)
Custom-made
Marine Grade Tinned Copper Cable
Klauke Crimping System
Crimped in accordance with BS7609
Description
Description
Made-to-Order Black OceanFlex 35mm² 2 AWG Flexible Marine Grade Tinned Cable
This marine-grade cable comes with customizable crimped end terminal options, including sizes:
- M8 (8.0mm hole diameter)
- M10 (10.0mm hole diameter)
- M12 (12.0mm hole diameter)
Also available cut-to-length with no connectors (bare ends).
Please contact us for any custom combination not shown.
Specifications:
- 35mm² Cable Conductor Cross-Section
- Conductor Specification (mm): 455/0.30
- Nominal Current Rating 240 Amps
- Maximum Overall Diameter: 11.8mm
- Tinned Copper Conductors in accordance with BS EN 60228:2005
- Yellow Cable - ISO 13297 compliant DC negative applications
- PVC Insulated - saves weight and offers good resistance to abrasion and cut through
- Minimum Bend Radius: <6x OD
- Suitable for use at temperatures from -30ºC to 70ºC
- Suitable for 12V and 24V systems (maximum 60V)
- Good resistance to petrol, diesel, lubricating oils and diluted acid
- Very good resistance to moisture
- Cables are printed with the specification on the insulation
Benefits of OceanFlex® Cable:
- Marine-specific flexible cable
- Tinned thin wall low voltage wiring cable designed for use in harsh environments
- In OceanFlex cable, the copper strands are tin-plated so the cable is highly resistant to corrosion from sea water over long periods of time.
- Oceanflex cables have a much greater life span compared to standard cables.
- This leads to lower repair/maintenance costs and less down time due to electrical faults and failures.
Red and yellow 35mm² cables are also available.
If you need a cable length or specification not shown on our website, please Contact Us with your requirements.
