Morningstar SunSaver 20L Solar Charge Controller 24V 20A
Morningstar SunSaver 20L Solar Charge Controller 24V 20A is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Datasheets
Datasheets
Delivery and Shipping
Delivery and Shipping
FREE & ECONOMY UK SHIPPING
We offer FREE Economy UK Delivery on all orders over £25 (2-4 business days).
Our standard delivery cost for UK orders under £25 is £5.00.
Large and heavy items will usually be sent via courier.
Smaller items will be sent by Royal Mail or Amazon Logistics.
EXPRESS UK SHIPPING
If you require an item urgently or within a short time
frame, please select the Express shipping option (1-3 working days).
The cost of this is calculated per order as it is based on
the weight of the products.
INTERNATIONAL SHIPPING
For EU Shipping – you can choose between Standard
Delivery (usually 2-11 days, subject to local customs) or Express Delivery
(usually 2-7 days, subject to local customs).
Worldwide, non-EU shipping times are 2-11 days.
(Please allow extra time for items to clear customs).
The cost of shipping for international orders is calculated per order as it is based on the weight of the products.
[All website prices include UK VAT at 20% - For orders
outside the UK, the 20% VAT will be removed during the checkout when you enter
the shipping destination.]
Description
Description
This Morningstar Sunsaver 20L solar charge controller is part of the third generation of SunSaver charge controllers.
These charge controllers are ideal for small professional and consumer systems. Fully encapsulated means they are approved for hazardous locations.
The unit has marine rated terminals for cable connection and includes a terminal cover.
There is a setting for sealed or vented batteries and this setting can be adjusted on the unit itself.
Features include:
- 3 LED's indicate to battery charge state and load disconnect condition.
- Full electronic protection & dead battery recovery feature.
- 4 stage battery charging
- Self-diagnostics to detect critical faults
- Telecom mode for sensitive loads
- Optional automatic low battery voltage disconnect (L).
Since its first market introduction in 1996, over 1 million SunSaver controllers have been installed in over 73 countries for various solar power systems including: oil/gas, telecom and instrumentation, marine and boating, and remote homes.
SPECIFICATIONS
- System Voltage: 24V
- Solar Current: 20A
- Load Current: 20A
- Low Voltage Disconnect: Yes
- Self-consumption: <8mA
- Wire Size: 5.0mm sq. / #10 AWG
- Protections: Over Load, Over Voltage, Low Voltage Reverse Polarity, High Temp, Lighting, Reverse Current at Night, Surge.
- Display: LED Indications for battery and system status.
Further specifications are available under the Datasheets tab.
